All FIP frames are sent over Ethernet (UDP)

Security : unidirectional gateway, transparent module on the FIP network

Dissecteur Wireshark

Control of the system via a Webserver

Data comfort sent over Ethernet

Design of PCB : recent

Provided with FIPWatcher spybus to received FIP frames on a remote system.

.

1 - General description
.

FiWiP is a compact system that includes the FIPWatcher mPCIe bus spy card and the "FIPGateway" module to Ethernet UDP. The module is "transparent" on the network so as not to disturb the FIP / WorldFIP network. This version is unidirectional and transparent so as not to be seen by the FIP network. The bi-directional version is accessible via the FIP-OPC UA module and the mPCIe FIP arbiter card.

.

2 - Hardware part
.

FiWiP is an embedded system powered by 24V.

For the FIP / WorldFIP part, the FIPWatcher mPCIe card offers:

A SUB-D9 to connect to the FIP / WorldFIP network

Optionally, a specific FIP frame acquisition start connector and an oscilloscope jack (missing in the installations) to connect to the FIP cable without disturbing it and analyzing the signal.

The system can be mobile (useful for maintenance) or fixed in an installation by a clip Din or 4 screw clip.

.

3 - Software part
.

The system is delivered with FIPWatcher software . Very easy to use, connect to the FIP network and Ethernet then connect the power supply, without any configuration, FIPWatcher detects and displays the FIP frames circulating on the network.

.

3-1 Modes of operation
.

.

FiWiP acts as a FIPWatcher protocol analyzer, very useful for desktop developments or on-site maintenance. Very easy to use, connect the screen, connect to the FIP network and then connect the power supply, without any configuration, FIPWatcher detects and displays the FIP frames circulating on the network.

It displays all the frames circulating on the network, with many features.

.

With the help of a Web Server ( Webmin for instance), remote administration system web interface, the user can configure the FIP UDP service, set the system time ...

In industrial installations, FiWiP remounts all FIP frames over Ethernet, encapsulating other "comfort or life" data (from the FiWiP module) such as temperature, memory or processor utilization rate ...

The remote device receives the UDP frames, to decode several possibilities:

- Use HMI FIPLabs

- Use Wireshark dissector

- Business application (customer integration)

All techical information, configuration and installation of FiWiP on our Wiki.

.

4 - Module included in the package

.

Wireshark dissector plugin: FIP frame dissector, packet visualization, filtering tools

UDP daemon FIP service

.

5 - Quotation and development
.

.

For a quotation, quantity discount, or a specific development fill the form below

.
